Polymer flange

for retrofit installation

HSI90 DFK

Add to wish list

Polymer flange - for retrofit installation

with integrated spirit level
Tested solution for use in pre-applied membrane sheet systems

For retrofit dowelling via core drill holes or for screwing onto housings. Used for the gastight and watertight connection of system seals for cables and cable ducts.

Data is sent to YouTube when the videos are played. The data protection statements of YouTube and Hauff-Technik apply.

Facts

Advantages:

System seal can be connected (e.g. cable duct connection or cable seal)
Can be installed on container walls
Form-closed surface seal

Scope of delivery:

Fixing elements including sealing ring
1 piece surface seal, 6 mm thick

Dimensions:

Length x width: 185 x 185 mm
Recommended centre distance for core drills: 200 mm
Core drills max. Ø: 100 mm
Build-up in front of the wall including surface seal: 40 mm

Application range:

Water exposure class DIN 18533: W1-E and W2.1-E
Waterproof concrete stress class 1 and 2

Material:

Flange: glass fibre reinforced polyamide
Surface seal: EPDM
Fastenings: stainless steel V4A (AISI 316L)

Tightness:

gastight and watertight to 2.0 bar

Downloads

Installation instructions

HSI90/HSI150 DFK (PDF, 1MB)

Test reports

Data sheet & tender specification

For download of data sheet and tender specification please configurate the product in the section below and download via the symbol Download symbol

Variants

Article code	Article number	GTIN
HSI90 DFK	3030466887	4052487240529	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity: Quantity:
HSI90 DFK OB ¹⁾	3030572403	4052487247313	Your download for the choosen variant: Data sheet Download (.pdf) Tender specifications GAEB XML (.x81) GAEB 90 (.d81) Text view (.txt) Word (.docx) Quantity: Quantity:
