Individual press seal

sealing width 30 mm

HRD b30

Configurator
This product has been marked in accordance with the FHRK test specification.
Tailor-made press seal in closed or split design for sealing new cables to be installed or cables that have already been laid. The seal is manufactured according to customer specific dimensional specifications - e.g. eccentric, with covering flange or for multiple and mixed entries.

Facts

Application range:

  • Waterproof concrete stress class 2, Standing seepage water, Pressurised water, Waterproof concrete stress class 1

Advantages:

  • Manufactured to the millimetre as appropriate for the prevailing installation conditions and in accordance with customer specifications
  • Maximum use of space for entries
  • Short delivery times

Scope of delivery:

  • Lubricating stick

Dimensions:

  • Sealing width: 30 mm
  • Press plates: 5 mm
  • For core drills/wall sleeves ∅: 40 mm and higher

Material:

  • Press plates, screws, nuts and washers: rust-free stainless steel V2A (AISI 304L), optional V4A (AISI 316L)
  • Rubber: EDPM, NBR, KTW or silicone

Tightness:

  • Gastight and watertight
Downloads

Brochures

Installation instructions

Test reports

Data sheet & tender specification

For download of data sheet and tender specification please configurate the product in the section below and download via the symbol

Configurator

Measured inner diameter (D):mm40-1500
Split design (G):
Covering flange (F):
Number of entries (Z):0-50 (0=Blind seal)
Measured outer diameter (d):mm5-1350

Eccentric (ex):mm>20
(Minimum distance between core drilling/wall sleeve and medium)
Material:

Your individual article designation:

Your individual article number:

Add to wish list
Download of data sheet
Tender specifications: TextWord

We cannot guarantee the feasibility of the configuration you have entered. If you have sent an enquiry, we will then check the configuration you have chosen again.
